Document Classes ⇒ elsarticle problem

[atul]

Hi,
I am a new to Latex and this community, but really fascinated by its capabilities and thus have determined not to go back to other word-processors.
But like any other new and cool thing facing problems every now and then.

I am using elsarticle to write my paper and not able to put figure in my article.

For adding figure, I am using

Code: Select all

\begin{figure}
\includegraphics[scale = 0.25]{simp_res_fig.eps}
\end{figure}

What I see on the generated PS file is attached.

So basically I can't see the image. Can someone please help me to figure out why is it so?

thanks,
-Atul

[localghost]

Omit the draft option either in the option list for the document class or the graphicx package. To avoid other issues with graphics files, don't use special characters like blank spaces or underscores in both the path and the name of the file.


Best regards and welcome to the board
Thorsten¹

[atul]

Thanks a lot.
Removing "draft" from document class solved the problem

-Atul
