Hi everyone !

I need to put 1 bloc and 3 images on 1 frame. I used this code :

Code: Select all

\begin{frame}\frametitle{The Mesh - Blades}

\begin{columns}
\begin{column}{0.5\textwidth}

	\begin{block}{Blades}
		\begin{itemize}
			\item Counter-rotating rotors,  Optimized blades
			\item $\sim 0.4$ million cells
		\end{itemize}
	\end{block}

\end{column}
\begin{column}{0.5\textwidth}

	\begin{figure}
		\begin{center}
    	\includegraphics[scale=0.11]{images2/b2.jpg}\\
		{{\footnotesize \emph{CAD version of the blades}}}
		\end{center}
	\end{figure}

\end{column}
\end{columns}

\begin{table}[ht]
	\centering
	\begin{tabu}to \textwidth {X[c]X[c]}
  		\includegraphics[width=52mm]{images2/b3.jpg}\captionof{figure}{blade root} &\includegraphics[width=52mm]{images2/b1.jpg}\captionof{figure}{Meshed blade}
	\end{tabu}
\end{table}


\end{frame}

but I can't get my images aligned nicely. Could you help me ?

This is my preamble :

Code: Select all

\documentclass[10pt,english]{beamer}
%%\documentclass[10pt,francais,handout]{beamer} %Pour un pdf plus facilement imprimable

\newenvironment{hblock}[2]{%
\begin{block}{#1}%
\begin{minipage}[c]{0mm}%
\etai[#2]%
\end{minipage}%
\begin{minipage}[c]{\textwidth}%
}{%
\end{minipage}%
\end{block}%
}

Also, I'd like not use \captinof as I do not want Figure to appear. What can I do ?

[Johannes_B]

Why don't you post a minimal working example?

[Colin93]

Code: Select all

\documentclass{beamer}

\usepackage{graphicx}
\usepackage{array}
\usepackage{multirow}
\usepackage{capt-of}
\usepackage{tabu}
\usepackage{xcolor}

\begin{document}
\title{Simple Beamer Class}
\author{Sascha Frank}
\date{\today}

\frame{\titlepage}

\frame{\frametitle{Table of contents}\tableofcontents}


\section{Section no.1}
\frame{\frametitle{Title}
Each frame should have a title.
}
\subsection{Subsection no.1.1  }
\frame{
\begin{columns}
    \begin{column}{0.5\textwidth}

            \begin{block}{Blades}
                    \begin{itemize}
                            \item Counter-rotating rotors,  Optimized blades
                            \item $\sim 0.4$ million cells
                    \end{itemize}
            \end{block}

    \end{column}
    \begin{column}{0.5\textwidth}

            \begin{figure}
                    \begin{center}
          \includegraphics[scale=0.11]{b2.jpg}\\
                    {{\footnotesize \emph{CAD version of the blades}}}
                    \end{center}
            \end{figure}

    \end{column}
    \end{columns}

    \begin{table}[ht]
            \centering
            \begin{tabu}to \textwidth {X[c]X[c]}
                    \includegraphics[width=52mm]{b3.jpg}\captionof{figure}{blade root} &\includegraphics[width=52mm]{b1.jpg}\captionof{figure}{Meshed blade}
            \end{tabu}
    \end{table}
}



\end{document}

Images :




[Colin93]

About \captinof, I found a way to get rid of the prefix Figure but when I'm in tabular environment, this doesn't work...

[Johannes_B]

What is your expected output? Can you draw a sketch?

Also, why are you using freaking tabu?

[Colin93]

Hi Johannes_B

Here's my expected layout. I'm using tabu 'cause that's what I found on the net... What should I use ? I'm pretty new at this...


[Johannes_B]

Like this?

Code: Select all

\documentclass{beamer}

\usepackage{graphicx}
\usepackage{capt-of}
\usepackage{caption}
\captionsetup{style=base}

\begin{document}
\title{Simple Beamer Class}
\author{Sascha Frank}
\date{\today}

\frame{\titlepage}

\frame{\frametitle{Table of contents}\tableofcontents}


\section{Section no.1}
\frame{\frametitle{Title}
Each frame should have a title.
}
\subsection{Subsection no.1.1  }
\begin{frame}{Blades}
	\begin{columns}
		\begin{column}{0.5\textwidth}
			\begin{itemize}
				\item Counter-rotating rotors,  Optimized blades
				\item $\sim 0.4$ million cells
			\end{itemize}
		\end{column}
		\begin{column}{0.4\textwidth}
			\centering
			\includegraphics[width=.5\linewidth]{example-image-b.jpg}\\
			{{\footnotesize \emph{CAD version of the blades}\par}}

		\end{column}
	\end{columns}

	\vspace{.1\textheight}
	\begin{tabular}{cc}
		\includegraphics[width=52mm]{example-image-c.jpg} &
		\includegraphics[width=52mm]{example-image-a.jpg} \\
		blade root &Meshed blade
	\end{tabular}
\end{frame}
\end{document}

[Colin93]

Exactly !!!! wow big thanks !
