[maloszybki]

Hi,

I have this code:

Code: Select all

\begin{figure}[!h]
	\begin{center}
		\subfigure[gwiazda]{
			\includegraphics[width=0.4\textwidth]{img/silnik-gwiazda.eps}
			\label{fig:silnik_sub_gwiazda}
		}
		\subfigure[trójkąt]{
			\includegraphics[width=0.4\textwidth]{img/silnik-trojkat.eps}
			\label{fig:silnik_sub_trojkat}
		}
	\end{center}
	\caption{Schemat elektryczny trójfazowego silnika bezszczotkowego \subref{fig:silnik_sub_gwiazda} -- gwiazda; \subref{fig:silnik_sub_trojkat} -- trójkąt (delta)}
	\label{fig:silnik}
\end{figure}

(rysunek \ref{fig:silnik}) | (rysunek \ref{fig:silnik_sub_gwiazda})

And here is rendered text from last line:

(rysunek 1) | (rysunek 2.1(a))

I expected another numeration. How I can get this:

(rysunek 1) | (rysunek 1(a))

I know I can use combination of \ref and \subref, but this is wrong way.

My class file is attached.

[jbgrad]

I am no Latex expert, but I've successfully done the following to a similar issue in my code. I added to the preamble:

Code: Select all

\renewcommand{\thesubfigure}{\arabic{figure}(\alph{subfigure})}

You'll notice a similar line in the file you attached:

Code: Select all

\renewcommand\thefigure{\@arabic\c@figure}

[cgnieder]

Hi maloszybki,

Welcome to the LaTeX community!

After I removed the dvips option to the graphicx package in main.cls (which isn't needed anyway, »graphicx« is quite possible of determining the right driver) I got the following MWE (minimal working example) running. (Note that I also replaced the {center} environment with \centering since the environment adds additional spacing.)

Code: Select all

\RequirePackage[demo]{graphicx}% this is only to black out the pictures as I don't have the eps files availyble
\documentclass{main}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc}
\usepackage{subfigure}
\begin{document}

\begin{figure}[!h]
  \centering
  \subfigure[gwiazda]{
    \includegraphics[width=0.4\textwidth]{img/silnik-gwiazda.eps}
    \label{fig:silnik_sub_gwiazda}
  }
  \subfigure[trójkąt]{
    \includegraphics[width=0.4\textwidth]{img/silnik-trojkat.eps}
    \label{fig:silnik_sub_trojkat}
  }
  \caption{Schemat elektryczny trójfazowego silnika bezszczotkowego \subref{fig:silnik_sub_gwiazda}
    -- gwiazda; \subref{fig:silnik_sub_trojkat} -- trójkąt (delta)}
  \label{fig:silnik}
\end{figure}

(rysunek \ref{fig:silnik}) | (rysunek \ref{fig:silnik_sub_gwiazda})

\end{document}

Apart from complaining that subfigure is obsolete (it has been superseded by subfig and even more recently by subcaption which is also better suiting to the caption package that is loaded in the class file) I cannot reproduce what you're saying:


So please add a minimal working example (maybe based on mine) that reproduces the unwanted behaviour.

Regards
