Graphics, Figures & Tables ⇒ IMAGE Problem, PNG File

[berat01]

Hi mates,

I'm trying to translate a book from german to turkish and i'm using TexMaker on Ubuntu 11.10 for this job. So i try to add some pictures to my work but it does not working. I'm using the following packages:

Code: Select all

\documentclass{scrartcl}
\usepackage[english,turkish]{babel}
\usepackage[utf8]{inputenc}
\usepackage[pdftex]{graphicx}
\usepackage[T1]{fontenc}
\selectlanguage{turkish}
\usepackage{color}
\begin{document}
...So the document begins...

If i add the image like this:

Code: Select all

\includegraphics[]{Abbildung1.png}

I get no error report.
But when i try to scale the image like this:

Code: Select all

\includegraphics[width=4cm, height=4cm]{Abbildung1.png}

or like this

Code: Select all

\includegraphics[scale=0.25]{Abbildung1.png}

it is not working anymore. What can be wrong? Does anyone have an idea??

Cheers

[Stefan Kottwitz]

it is not working anymore. What can be wrong?

Do you get an error message? If you don't see a message, perhaps post the .log file here, as attachment.

Stefan

[berat01]

When i run it as PDFLateX i become this message; "Process exited with error(s)"

This is the image;

[Stefan Kottwitz]

When i run it as PDFLateX i become this message; "Process exited with error(s)"

So there are errors, but we need to know the errors (or your source code) to be able to help. Perhaps attach your .log file, it contains the error messages.

Stefan

[berat01]

I do not understand. In the log is the followings written:

Code: Select all

Dimensions can be in units of em, ex, in, pt, pc,
cm, mm, dd, cc, nd, nc, bp, or sp; but yours is a new one!

But i am writing this code;

Code: Select all

\includegraphics[width=4cm, height=4cm]{Abbildung1.png}\\

So my units are given in cm.

[Stefan Kottwitz]

The errors in the .log give gave me sufficient information. I noticed that the problem is caused by using the turkish babel features. This makes the = sign an active character and interferes with the key=value interface. You could switch it off, if you don't need it - after \begin{document}, i.e.

Code: Select all

\documentclass{scrartcl}
\usepackage[english,turkish]{babel}
\usepackage[utf8]{inputenc}
\usepackage[pdftex]{graphicx}
\usepackage[T1]{fontenc}
\selectlanguage{turkish}
\usepackage{color}
\begin{document}
\shorthandoff{=}
\includegraphics[width=4cm, height=4cm]{Abbildung1.png}\\
\end{document}

Btw. the option pdftex is usually not required, the driver should be auto-detected.

Stefan

[berat01]

Thank you Stefan. It worked. You are the savior
Berat
