General ⇒ PSTricks compile problem with Miktex 2.9 and Texniccenter

[Tobias_Denmark]

Hello,

I have formatted my computer and re-installed Miktex 2.9, Texniccenter and Adobe Reader 10, but now I have problem with compiling my latex documents. I did not have any problems before with PSTricks, but now it want's auto-pst-pdf, -enable-write18 and so on...

What is wrong?

This is the output file:

Code: Select all

Package auto-pst-pdf Warning:
    Creation of test-pics.pdf failed.
This warning occured on input line 124.


Package auto-pst-pdf Warning:
    Could not create test-pics.pdf. Auxiliary files not deleted.
This warning occured on input line 124.

Package pst-pdf Warning: pspicture No. 1 undefined.

)

Package pst-pdf Warning: File `test-pics.pdf' not found.
(pst-pdf)                Use the following commands to create it:
(pst-pdf)                ----------------------------------------------------
(pst-pdf)                latex test.tex
(pst-pdf)                dvips -o test-pics.ps test.dvi
(pst-pdf)                ps2pdf test-pics.ps
(pst-pdf)                ---------------------------------------------------- .

[frabjous]

Which of TeXnicCenter's output routines are you using?

[Tobias_Denmark]

Hi,

I'm using the LaTex => PDF, with Command line arguments to pass to the compiler: -enable-write18 -interaction=nonstopmode "%pm"

/Tobias

[frabjous]

I think within a pspicture environment, you need to use .eps graphics. I'd convert that .jpg and .pdf to .eps files and see if that helps.

[Tobias_Denmark]

Thanks frabjous, tried it, but no luck

(Could not upload the PDF to EPS picture I had due to max picture size..)

[Tobias_Denmark]

Hello everyone again.

Anyone able to help me?

regards

Tobias
