Graphics, Figures & Tables ⇒ EPS figure withe strange output format in latex!!!

[Sam]

Dear all,

I am not quite sure why when i save my drawing as .esp figure from INKSCAPE...i get a weired text...

please see below...

thanks for help

[localghost]

Obviously a malfunction during the export process. Seems that the preamble is missing. It should look similar to the following.

Code: Select all

%!PS-Adobe-2.0 EPSF-2.0
%%Title: 20010613.eps
%%Creator: gnuplot 3.7 patchlevel 1
%%CreationDate: Tue Aug 07 20:42:00 2001
%%DocumentFonts: (atend)
%%BoundingBox: 50 50 410 302
%%Orientation: Portrait
%%EndComments

Thorsten

[php1ic]

That text is raw postscript (or eps) code, so it looks like latex may not be interpreting the graphics properly. Can you post an MWE to show how you include the file.

Can you view the eps 'normally' outside of latex?

[Sam]

That text is raw postscript (or eps) code, so it looks like latex may not be interpreting the graphics properly. Can you post an MWE to show how you include the file.

Can you view the eps 'normally' outside of latex?

Yes I could see the .eps normally outside latex.

what is MWE please?

[localghost]

[…] what is MWE please?

You are a board member for more than three years now and still don't know what a MWE is?! You have already been given according links in some of your former requests (and obviously didn't follow them). So here are some reminders [1-4]. It is expected that you follow the links and the instructions you will find ([1], [2] or [3] and [4]).

[1] TeX FAQ — How to make a “minimum example”
[2] What is a minimal working example?
[3] How to create a LaTeX minimal example
[4] View topic: Avoidable mistakes
