Hi,
Depending on what exactly do you have in mind, there are couple of things regarding this:
1. If you want an inline graphic, just use
Insert > Graphics... (not float). This is useful, e.g., in manuals, when you need to insert icons and similar very small figures which fit in a line of text.
2. If you want text to wrap around a figure, you may use
Insert > Float > Figure Wrap Float to place a figure inside a text and make text wrap around it. Right click on
wrap:Figure > Settings will allow you to further customize the appearance of the figure.
3. You may use a table (
Insert > Table with two columns and a row to put graphics in one and text in the other cells, or use two boxes/minipages (
Insert > Box).
I attached a simple example file which you can use to study how these work.
P.S. Don't use external links for pictures and other material, rather upload them directly here. Please read
Board rules. And welcome to our community
