potatp · Post by **potatp** » Wed Sep 30, 2009 5:14 pm

Hi! I don't know why I can't get the same quality on my outputs, when I type text and when I type maths.
Anyone can help me please?

: 1.PNG (2.42 KiB) Viewed 2832 times

: 2.PNG (7.83 KiB) Viewed 2832 times

NEW: TikZ book now 40% off at Amazon.com for a short time.

Post by **Stefan Kottwitz** » Wed Sep 30, 2009 5:27 pm

Hi potatp,

welcome to the board!
Perhaps the problem is caused by a missing font with the appropriate encoding. You could try to solve it by installing the cm-super package. I've seen it often that lower quality appeared because of T1 encoding but missing T1-fonts. cm-super provides standard Computer Modern fonts with T1 encoding.

Stefan

phi · Post by **phi** » Wed Sep 30, 2009 5:54 pm

This behavior arises when you use the T1 font encoding but don't load a vector font that provides that encoding. Loading the lmodern package should fix it in most cases.

potatp · Post by **potatp** » Wed Sep 30, 2009 6:18 pm

Thank you two! that was fast. Solved!
